Single-way PFC

Features:

1. Input voltage range: 90~264VAC/100~370VDC

2. AC and DC dual-purpose (input voltage at the same terminal)

3. Working temperature range: -40℃ to +85℃

4. Low standby power consumption and high efficiency

5. 4000VAC high isolation voltage

6. Low ripple noise

7. Size 5000m altitude applications

8. Output short circuit, overcurrent, overvoltage protection

9. Overvoltage level III (compliant with EN62477)

10. Comply with IEC/EN/UL/BSEN62368, EN60335, EN61558, EN62477, GB4943 and other certification standards

Series title	power	Input voltage (VAC)	Input voltage (VDC)	Output voltage	size
BOF-60S▼ ▲	60W	90V~264V	100V～370V	12V	76.2×50.8×24MM
BOF-75S▼ ▲	75W	90V~264V	100V～370V	12V	76.2×50.8×24MM
BOF-100S▼ ▲	100W	90V~264V	100V～370V	12V	127×76.2×33mm
BOF-120S▼ ▲	120W	90V~264V	100V～370V	12V	127×76.2×33mm
BOF-125S▼ ▲	125W	90V~264V		3.3V,5V,12V,13.5V,15V,24V,27V,48V	127×76.2×30.5mm
BOF-150S▼ ▲	150W	90V~264V	100V～370V	12V,18V,24V,36V,52V,54V	127×76.2×33mm
BOF-180S ▼ ▲	180W	90V~264V	100V～370V	18V	127×76.2×35mm
BOF-200S▼ ▲	200W	90V~264V		52V	127×76×35mm
BOF-200SN▼ ▲	200W	90V~264V		3.3V,5V,7.5V,12V,15V,24V,36V,48V	140×35×25mm
BOF-280S ▼ ▲	280W	90V~264V		12V	127×76.2×35mm
BOF-290S ▼ ▲	290W	90V~264V		54V	188×83×33mm
BOF-300S ▼ ▲	300W	90V~264V	240V～370V	50V	210×110×33mm
BOF-400S ▼ ▲	400W	90V~264V	100V～370V	52V	220×100×38mm
BOF-409S ▼ ▲	409W	90V~264V		54V	170×100×33mm
BOF-450S ▼ ▲	450W	90V~264V		54.5V	170×100×33mm
BOF-460S ▼ ▲	460W	90V~290V	190V～290V	56V	190×85×38mm
BOF-550S▼ ▲	550W	90V~264V		52V	127×76.2×35mm
BOF-750S▼ ▲	750W	90V~264V		52V	127×76.2×35mm
BOF-600S▼ ▲	600W	90V~264V		12V,24V,36V,48V,52V,54V	227×86×36mm
BOF-800S▼ ▲	800W	90V~264V		52V	227×86.2×34mm
BOF-1000S▼ ▲	1000W	90V~264V		52V	227×86.2×34mm
